1. Accuracy & Dynamic Positioning / Repeatability
Three‑axis positioning accuracy: ±0.001 mm
A/C‑axis accuracy: ±3 arcseconds
Simultaneous 5‑axis machining accuracy: ±0.005 mm
Full closed‑loop control + thermal management: linear scales, ballscrew core cooling, A/C‑axis cooling → excellent thermal stability, minimal accuracy loss over long machining cycles
2. High‑rigidity cast construction
Dual direct‑drive (DD) motors for A and C axes
High torsional rigidity, low cradle deformation, stable heavy‑duty cutting
3. Typical applications
Precision complex molds (injection, die‑casting, stamping)
Impellers, turbines, aerospace structural parts
Multi‑face machining in a single setup
4. Advantages compared to standard 5‑axis machines
Higher rigidity, better thermal stability, superior dynamic accuracy
A compact high‑precision 5‑axis machining solution offering high rigidity, excellent thermal stability, and fast dynamic response
The top choice for molds and complex parts
